| Quantity: | |
|---|---|
| Main Technical Parameters: | |
| Travel (m): | 267mm (10.5") |
| Blowing Medium: | Compressured air or Steam |
| Travel Speed (mm/min): | 290 |
| Rotation Speed (r.p.m): | 2.3 |
| Blowing time: | 2.76min (one circle) |
| 3.62min (two circles) | |
| 4.49min (three circles) | |
| Blowing Radius (m): | 1.5~2 |
| Nozzle caster angle: | 3° |
| Motoer Specification: | 0.18KW, 1370rpm, 380V, 50Hz |
| Approx. Weight: | 110kg |
Main Components:
1. Poppet Valve
2. Feed tube
3. Lance tube and Nozzle
4. Reduction Gear
5. Guide rod system
6. Casing Protection cover
7. Electric control assembly
8. mounting device in Furnace
| Main Technical Parameters: | |
| Travel (m): | 267mm (10.5") |
| Blowing Medium: | Compressured air or Steam |
| Travel Speed (mm/min): | 290 |
| Rotation Speed (r.p.m): | 2.3 |
| Blowing time: | 2.76min (one circle) |
| 3.62min (two circles) | |
| 4.49min (three circles) | |
| Blowing Radius (m): | 1.5~2 |
| Nozzle caster angle: | 3° |
| Motoer Specification: | 0.18KW, 1370rpm, 380V, 50Hz |
| Approx. Weight: | 110kg |
Main Components:
1. Poppet Valve
2. Feed tube
3. Lance tube and Nozzle
4. Reduction Gear
5. Guide rod system
6. Casing Protection cover
7. Electric control assembly
8. mounting device in Furnace
