KINDS OF GENERATOR CARBON BRUSH

Recently, we faced some client to ask for the carbon brush.  Based on our experience, we would like to share with whom need help on choosing carbon brush for Generator.

Client: " if we did not have the original drawing or brand, is that possible you supply?"

answer: " Yes, if you can supply the material and dimension requirement, we can supply."

Client: " How many different materials from China Generator manufacture?"

Answer: " There are different kinds of materials, such as D104, D172, S27, LFC554 and NCC634. It is depend on the

Generator technical specifications."

Client: " How about your dimension supply ?"

Answer: " we normally supply the dimensions such as 12.5*12.5*25, 12.5*10*32, 32*25*60, 32*20*40, 40*32*80, the unit is mm. "

Client: "Can you give me more instructions for that? "

Answer: " Sure. For Grounding Type Generator Carbon Brush normally used as D104 (12.5*12.5*25mm), D172 (12.5*10*32mm), D172 (32*20*40mm). But excitation model generator carbon brush normally used as D172 (32*25*60mm), N34 (2*(16*25*40mm)), S27 (32*25*60mm), LFC554 (40*32*80mm), NCC634 (40*32*80mm)."

Finally, we would like to share with you, if you want to replace the previous carbon brush of generator, please check and confirm the material and detail dimensions as following example. We can supply the completely support to you for that.
